ZxMPlus Series Parts Catalog

Drive System Components

Item

Number

Description Part Number

Kit

Quantity

1 Kit Ribbon Take-Up Clutch ZxM+ & ZMx00 77814M 1

2 Kit Drive Pulley Gear System 77803M 1

3 Main Drive Belt, 144T 77396 1

4 Stepper Motor Assy Kit ZxM+ & ZMx00 G77813M 1

5

1 2 3 4 5 6 7 8 9 10

ZxMPlus Series Parts Catalog 1
